滚轮轴承

这条产品线下的系列

点击下面任意系列查看型号。具体型号、尺寸、替代参考号，发图纸或型号给我们。

SG Series ⌄

Countersunk design

型号	d × D × B (mm)
SG20/25	8×25×
SG24/3	6×24×
SG66/21	6×21×
SG10	4×13×6BOOS SG10
SG15	5×17×8BOOS SG15
SG20	6×24×11BOOS SG20
SG22	6×22×10BOOS SG22
SG24	8×24×11BOOS SG24

22 models in this series · 询价 →

Ultra-compact for flat guide rails and tight spaces

LFR Series ⌄

Standard flanged

型号	d × D × B (mm)
LFR50/4NPP	4×5×
LFR50/5-4KDD	5×4×
LFR50/5-4NPP	5×4×
LFR50/5KDD	5×6×
LFR50/5NPP	5×6×
LFR50/8KDD	8×6×
LFR50/8NPP	8×6×
LFR5201-12KDD	12×12×

31 models in this series · 询价 →

General-purpose linear guide rollers

LV Series ⌄

V-groove design

型号	d × D × B (mm)
LV20/7	7×22×11
LV20/8	8×30×14
LV200-32	10×32×14
LV201	12×41×20
LV201-14	12×39.9×20.1
LV201-35	12×35×15.1
LV202-38	15×38×17
LV202-40	15×40×18

34 models in this series · 询价 →

For V-profile guide rails

VW Series ⌄

Linear motion

型号	d × D × B (mm)
VW W0	4×14.84×6.35
VW W0X	4×14.84×6.35
VW W1	4.763×19.56×7.87
VW W1SSX*	4.763×19.56×7.87
VW W1X	4.763×19.56×7.87
VW W2	9.525×30.73×11.1
VW W2SSX*	9.525×30.73×11.1
VW W2X	9.525×30.73×11.1

20 models in this series · 询价 →

Precision linear guide applications

Ring Slides (Turntable)⌄

Circular motion · Custom diameter

Rotary tables and curved guide tracks. Ring slide bearings are typically custom-sized to the turntable diameter — not a standard catalog series.

Ring slides are custom — send your turntable diameter or drawing. 询价 →

Bevelling Machine Bearings⌄

Pipe beveling · Chamfering machines

Specialized roller bearings for pipe beveling and chamfering equipment (坡口机/斜切机). Includes V5200-2RS, 4000TNFB-2RS, 4002TNFB-2RS variants — interchange reference for imported beveling machine spares.

型号	d × D × B (mm)
加载中……

加载中……

FV30 Series ⌄

Flat guide · Heavy-duty

Send us your part number or drawing for this series. 询价 →

Flat-surface track rollers for heavy-duty linear guides. Wider contact surface than crowned types, distributes load over larger area. For industrial doors, heavy conveyors and material handling.

75/76 Series (Inch Track Rollers)⌄

Inch dimensions · 75xx · 76xx

Inch-size track rollers for North American equipment and repair market. Compatible with common inch-rail guide systems. Stud-type and yoke-type available.

Inch-size track rollers. Send your inch part number. 询价 →

可选配置（询价时确认）

Profile: Flat / V-groove / Crowned
Material: Bearing Steel / Stainless Steel
Seal: Shielded / Sealed / Open

具体配置按报价单确认。我们不说每个型号每个配置都有现货——核实后再报。
