农机轴承

这条产品线下的系列

点击下面任意系列查看型号。具体型号、尺寸、替代参考号，发图纸或型号给我们。

Round Bore Insert (KRR Series)⌄

203KRR2 · 204KRR2 · 205KRR2 · 206KRR2

Most common agricultural insert bearing. Eccentric locking collar, heavy rubber seals. Bore range 5/8" to 1-3/8" (inch) or 17-40mm (metric). For disc harrows, planters, cultivators.

型号	d × D × B (mm)
203KRR2	16.256×40×18.288LLHB 203KRR2
203KRR5	16.256×40×18.288LLHB 203KRR5
6201 2RST	12×32×10LLHB 6201 2RST
6203 2RST	17×40×12LLHB 6203 2RST
Z9504	19.05×45.212×15.494LLHB Z9504

5 models in this series · 询价 →

Wide Inner Ring Inserts⌄

WIR · Pillow block compatible

Extended inner ring for direct mounting on shaft without adapter. Compatible with standard pillow block and flange housings (Pillow blocks UCP/UCF series).

Wide inner ring insert bearings compatible with standard pillow block and flange housings. Send your housing part number. 询价 →

Tapered Roller Agricultural ⌄

Cone + Cup sets · Trailer hubs

型号	d × D × B (mm)
PER.25580/20	44.45×82.931×23.812SKF PER.25580/20
PER.25590/20	45.618×82.931×23.812SKF PER.25590/20
PER.25877 and PER.25821	34.925×73.025×23.812SKF PER.25877 and PER.25821
PER.2790/20	33.338×76.2×23.812SKF PER.2790/20
PER.33889 and PER.33821	50.8×95.25×27.783SKF PER.33889 and PER.33821
PER.342A-A and PER.332	41.275×80×28.575SKF PER.342A-A and PER.332
PER.3780/20	50.8×93.264×30.162SKF PER.3780/20
PER.387AS and PER.382A	57.15×96.838×21SKF PER.387AS and PER.382A

25 models in this series · 询价 →

Tapered roller bearings for tractor and implement wheel hubs, trailer axles and heavy-shock-load pivot points. Higher load capacity than ball-type inserts.

Sealed Units (Triple-Lip)⌄

Triple-lip rubber · Labyrinth

Maximum protection against field contaminants: mud, fertilizer, water, dust. Triple-lip rubber seal or labyrinth non-contact seal options. Grease-packed for life.

型号	d × D × B (mm)
3202 CETN9	15×35×15.9SKF 3202 CETN9
3206 CE-2RSH1TN9	30×62×23.8SKF 3206 CE-2RSH1TN9
3207 CE-2RSH1TN9	35×72×27SKF 3207 CE-2RSH1TN9
3207 CETN9	35×72×27SKF 3207 CETN9
3306 CE-2RSH1TN9	30×72×30.2SKF 3306 CE-2RSH1TN9
3306 CETN9	30×72×30.2SKF 3306 CETN9
3307 CE-2RSH1TN9	35×80×34.9SKF 3307 CE-2RSH1TN9
3307 CETN9	35×80×34.9SKF 3307 CETN9

236 models in this series · 询价 →

SKF Agri Compatible ⌄

SKF Agri references · PER series

型号	d × D × B (mm)
22208 E	40×80×SKF 22208 E
22211 E	55×100×SKF 22211 E
22213 E	65××SKF 22213 E
22213 E/C3	65×120×SKF 22213 E/C3
23220 CC/W33	100××SKF 23220 CC/W33
3201 ATN9	12×32×SKF 3201 ATN9
3204 CE-2RS1TN9/C3	20×47×SKF 3204 CE-2RS1TN9/C3
3214 A	70×125×SKF 3214 A

524 models in this series · 询价 →

We declare compatible references for SKF Agri seal and bearing units (PER series, hub units). Dimensions and function match — not authorized, not affiliated.

Custom Agricultural ⌄

Drawing-based

Send us your part number or drawing for this series. 询价 →

Special bore sizes, non-standard seals, custom grease fill for specific OEM equipment. Send your drawing or sample for a custom quote.

可选配置（询价时确认）

Seal: Triple-lip rubber / Labyrinth
Material: Bearing Steel
Mounting: Eccentric / Concentric collar

具体配置按报价单确认。我们不说每个型号每个配置都有现货——核实后再报。
